Buy RPC-4224 4U Server Case w/ 24 Hot-Swappable SATA/SAS Drive Bay, MiniSAS connectorRPC-4224 4U Server Case w/ 24 Hot-Swappable SATA/SAS Drive Bay, MiniSAS connector Product Description:
- 4U rackmount ,24x hot-swappable SATA (I or II) / SAS drive bays.
- Six internal SFF-8087 Mini SAS connectors support up to twenty-four 3.5" or 2.5" SATA (I or II) or
- Ball-bearing cooling fans for better ventilation,
- SAS hard drives;Hot-swappable HDD tray with special designed power-off and lock mechanism.24 x 3.5 " hot-swappable drive bays.
- CEB(12"x10.5"), ATX (12"x9.6"), Micro ATX (9.6" x 9.6") motherboard
- RoHS Compliant Redundant 4pin molex PSU connectors support redundant power supply Support EEB (12"x13"),
- Screwless top cover Smooth border prevent lacerating your skin
Product Description
Drive Bay: 24 x hot-swappable SATA (I or II) / SAS drive bays
Cooling Fan: 4 x 80mm middle fans wall, 2 x 80mm rear fans
Switch: Power ON/OFF x 1, System reset x 1
Indicator:Power ON/OFF x 1, HDD x 1, NETWORK X 2
Connector:Two front accessible USB ports, six internal SFF-8087 Mini SAS connectors, twelve 4-pin molex redundant power connectors
Motherboard Compatibility: Support EEB (12"x13"), CEB(12"x10.5"), ATX (12"x9.6"), Micro ATX (9.6" x 9.6")
Power Supply Options: Standard ATX power supply, mini redundant power supply (H x W: 5.91" X 3.39")
Dimensions ( W x D x H ): 19" x 25.5" x 7.0" (483mm x 650mm x 176mm)
Packing:Double boxes
Weight (without hard drive): 18 kg/39.7 lb (NET) 21.2 kg/46.7 lb (GROSS)
Environment Temperature:0/40 °C, 32/104 °F (Operating) -20/60 °C, -4/140 °F (Non-Operating)
Relative Humidity: 5% to 95%,non-condensing
Customer Reviews
Most helpful customer reviews
8 of 8 people found the following review helpful.
Very good case, 1 or 2 minor annoyances
By NotLarryEllison
A beautiful idea - quickly throw together serious wads of disk space for just a few grand. This product, teamed with commodity PC parts, a semi-enterprisey RAID card and a bunch of SATA drives, can create just such a beast. If you want a bit more protection, get a redundant power supply. If you want to pay even less - or depending on your application - use something like FreeBSD running ZFS (software RAID, more or less) and a cheap SAS Expander.The fansThere are 6-80mm fans in this thing and they are loud as hell. In a server room you won't care, but just about anywhere else you'll go crazy. This 120mm fan "plate" that can be swapped in may help: 120mm fan wall bracket. I don't have any personal experience with it, but for about 11 bucks it's probably worth a shot. That, along with a fan speed controller, may bring the noise down to reasonable levels. The fans all use old-school Molex power connectors so there's no way to connect them to motherboard fan headers without adapters. It would be easy enough to cobble one together, but I've looked around both on Amazon and monoprice and haven't yet found a pre-made 3-pin fan header-to-molex power adapter or cable.Backplane connectionsYou'll need SFF-8087 connectors to hook up your disks to whatever motherboard, RAID card or SAS Expander you're using. SFF-8087 allows you to make four disk connections via one cable. If you're going from this backplane to your motherboard's SATA connectors, be aware that you'll need what's called a REVERSE breakout cable, not the forward breakout.The access to the disk backplanes is a bit cramped because the "Wail of Hades Fan Plate" (the plate containing four 80mm fan right behind the drives) sits just a couple of inches back from these connectors. That makes it a bit of a challenge to get both the SFF-8087 connectors as well as the Molex power connectors hooked up. There's a ton of space behind this fan plate, so I wish it was located about 1 inch farther towards the back of the case. Perhaps Norco purposely puts it closer because some larger server motherboards or redundant PSU's might then get cramped. In any case, this is generally just a one-time experience, so once you've got everything hooked up you're likely to never have to worry about it again.In the first RPC-4224 I received (I've ordered two of them so far), two of the 24 drive bays were dead. Since I was only hooking up a total of 15 drives (13 storage & 2 mirrored system drives) I was able to work around it very easily. I've seen other reviewers with the same complaint, and from what they say, Norco is VERY responsive about getting these problems addressed. Apparently, swapping out these backplanes is fairly straightforward, but I didn't bother to pursue it. I took off one star because this looks like a persistent issue.What I did with this thingI put together a 32 TB system using this case, a Gigabyte Z68 motherboard, Intel 2500K CPU, and 8 GB RAM. Those parts were installed into this case along with one Megaraid Sas 9260-16I Single, 16-PORT Int, 6GB/S Sata+sas, Pcie 2.0, 512MB; In T and 13 Hitachi Deskstar 3.5 Inch 3 TB CoolSpin SATA 6Gb/s Internal Hard Drive Retail Kit 0S03228. Running those disks on that controller in RAID 6 nets just over 32 TB of storage. It's not the fastest disk subsystem in the world - you don't want to run your main SQL databases on it, for example. But we've been backing up our production databases to it at work (as part of a disk to disk to tape strategy) and it's substantially faster than the HP SAN we were previously using. The HP SAN I just mentioned is a few years old, so I'm not saying that this setup is faster/better than enterprise SAN technology. But that SAN was considered state of the art not that long ago.If anything breaks on this "backup server," in an emergency I can head over to Fry's and pick up just about anything I need and be back up and running in at most a couple of hours. Hell, for a fraction of the price of just about any other "true enterprise" SAN solution with comparable capacity (especially with the SAN's support costs) I could build TWO of these boxes and have complete redundancy top to bottom, then use rsync to efficiently keep all our backup data synchronized across both machines.As far as power consumption goes, I'd bet that even though I'd be doubling up on my disks, two complete sets (64 TB in all across the two machines) of these low-power Hitachis would compare favorably with an Enterprise SAN using 2.5" drives. Since I'm getting ~3 TB per low-power drive and the 2.5" units would have much less capacity, it would have to use a lot more disks to get to 32 TB. I with I had the equipment necessary to accurately do a comparison.
1 of 1 people found the following review helpful.
Norco is making servers for everyone!
By Peter Kvalsvik
This TANK of a server cabinet makes huge storage arrays possible for everyone! At this prize, you can really get to build your own server, and not go bankrupt!And although there has been some problems with the backplane's in the Norco cabinets, the Norco customers support is extremely helpful and sends you the new parts right away, so no worries!Only thing to notice is that this is a server cabinet. Place this in your living room or bedroom, and your wife will go mad, as and array of 24 hard drives, and the rest of the system, requires a LOT of cooling, and the fans inside, really does the job... but they really makes a noise.Please see the discussion, as i have answered a lot of questions you might have for this product!
0 of 0 people found the following review helpful.
great case, well designed
By Tim H
I am using this case for a NAS running FreeNASI only have 8 drives in it right now but it has been much nicer than my old casethe internal SAS backplane makes things nice by eliminating as many cables as possibleno complaints from me except I wish the prices of drives would come back down so I could fill it up some more
See all 3 customer reviews...Latest Price:
